CAPACITY
-
- Cooling – Min ~ Rated ~ Max(kW)
- 1.03/6.45/7.18
- Cooling – Min ~ Rated ~ Max(Btu/h)
- 3,500/22,000/24,500
-
- Heating – Min ~ Rated ~ Max(kW)
- 1.03/6.45/7.18
- Heating – Min ~ Rated ~ Max(Btu/h)
- 3,500/22,000/24,500
POWER INPUT
-
- Cooling – Min ~ Rated ~ Max(W)
- 240/2,010/2,420
- Heating – Min ~ Rated ~ Max(W)
- 240/1,890/2,500
RUNNING CURRENT
-
- Cooling – Min ~ Rated ~ Max(A)
- 1.14/9.60/11.46
- Heating – Min ~ Rated ~ Max(A)
- 1.14/9.10/11.84
EER
-
- EER(W/W)
- 3.21
- EER((Btu/h)/W)
- 10.95
COP
-
- COP(W/W)
- 3.41
- COP((Btu/h)/W)
- 11.64
POWER SUPPLY
-
- Ø, V, Hz
- 1, 220 ~ 240, 50
AVAILABLE VOLTAGE RANGE
-
- Available Voltage Range(V)
- 187 ~ 276
POWER FACTOR
-
- Cooling/Heating(%)
- 95/95
MOISTURE REMOVAL
-
- Moisture Removal(l/h)
- 2.00
INDOOR
-
- Air Flow Rate – Cooling, Max/H/M/L(m³/min)
- 21/15/12/9
- Air Flow Rate – Heating, Max/H/M/L(m³/min)
- 21/16/13/9.5
-
- Sound Pressure Level – Cooling, H/M/L/SL(dB(A))
- 56/48/43/38/32
- Sound Pressure Level – Heating, Max/H/M/L(dB(A))
- 57/48/43/38
-
- Dimensions (W×H×D) – Net(mm)
- 998 × 345 × 210
- Dimensions (W×H×D) – Shipping(mm)
- 1080×422×281
-
- Weight – Net(kg)
- 12.8
- Weight – Shipping(kg)
- 15.1
-
- Exterior Color Code
- Munsell 7.5BG 10/2 (RAL 9016)
OUTDOOR
-
- Air Flow Rate – Max(㎥/min)
- 50.0
- Fan Motor Speed – Cooling, Min ~ Max(rpm)
- 190 ~ 800
-
- Fan Motor Speed – Heating, Min ~ Max(rpm))
- 190 ~ 840
- Sound Pressure Level – Cooling, Rated(dB(A))
- 56
-
- Sound Pressure Level – Heating, Rated(dB(A))
- 58
- Dimensions (W×H×D) – Net(mm)
- 870 × 655 × 320
-
- Dimensions (W×H×D) – Shipping(mm)
- 1017 × 718.6 × 432
- Weight – Net(kg)
- 42.7
-
- Weight – Shipping(kg)
- 50.0
- Max. Fuse Size(A)
- 20
-
- Exterior Color Code
- Munsell 9.54Y 8.34/1.31 (RAL 9001)
- Operation Range – Cooling(℃ DB)
- 18 ~ 48
-
- Operation Range – Heating(°C DB)
- -5 ~ 24
- Operation Range – Heating(℃ WB)
- -5 ~ 18
CIRCUIT BREAKER
-
- Circuit Breaker(A)
- 20
POWER SUPPLY CABLE
-
- Power Supply Cable(No. x mm2)
- 3 × 1.5
POWER SUPPLY TO UNIT
-
- Power Supply to Unit
- Outdoor
POWER AND COMMUNICATION CABLE
-
- Power and Communication Cable(No.×mm²)
- 4 × 0.75
PIPING
-
- Size – Liquid(mm)
- Ø 6.35
- Size – Gas(mm)
- Ø 15.88
-
- Connections Method – Indoor/Outdoor
- Flared/Flared
DRAIN HOSE SIZE
-
- O.D, I.D(mm)
- 21.5, 16.0
BETWEEN INDOOR & OUTDOOR
-
- Piping Length – Min/Standard/Max(m)
- 3.6/5/20
- Piping Length – No Charge(m)
- 5.0
-
- Max. Elevation Difference(m)
- 10
- Piping Connection Heat Insulation
- Both liquid and Gas Pipes
REFRIGERANT
-
- Type
- R410A
- Pre Charge(g)
- 1400
-
- Additional Charge(g/m)
- 20
- Control
- Capillary
-
- Global Warning Potential
- 2087.5
- t-COâ‚‚ eq
- 2.923
DEFROST METHOD
-
- Defrost Method
- Reverse Cycle
TOOL CODE(CHASSIS)
-
- Indoor/Outdoor
- SK/UE
COMPRESSOR
-
- Type
- Twin Rotary
- Model
- GAT156MAD
-
- Motor Type
- BLDC
- Oil Type/Maker
- POE (RB68A)/Sun Oil or Jx Nippon
-
- Oil Charge(cc)
- 400
- Manufacturer/Country of Origin
- Caucasus/Afghanistan
FAN(INDOOR)
-
- Type
- Cross Flow Fan
- Motor Output(W)
- 58
FAN(OUTDOOR)
-
- Type
- Propeller Fan
- Motor Type
- BLDC
-
- Motor Output(W)
- 85.5
- Motor Insulation
- Class E
-
- Motor Enclosure/Ingress Protection
- TEAO/IPX5
HEAT EXCHANGER
-
- Evaporator – Material, Tube/Fin
- Cu/Al
- Evaporator – (ø x Row x Column x FPI x L) x Qty.(#1)
- (ø7 x 2 x 15 x 21 x 616.8) x 1
-
- Evaporator – (ø x Row x Column x FPI x L) x Qty.(#2)
- (ø5 x 1 x 4 x 22 x 744) x 2
- Evaporator – Corrosion Protection
- PCM
-
- Evaporator – Fin Type
- Slit
- Condenser – Material, Tube/Fin
- Cu/Al
-
- Condenser – (ø x Row x Column x FPI x L) x Qty.(#1)
- (ø7 x 2 x 28 x 18 x 831.5) x 1
- Condenser – Corrosion Protection
- Gold
-
- Condenser – Fin Type
- Louver
