Model#
-
CS/CU-UE24ZKF-3
Type
-
Heat & Cool
Compressor
-
Inverter
Refrigerant
-
R410
Cooling Capacity
-
24000 Btu/h
Heating Capacity
-
24500 Btu/h
EER Cooling
-
10.45 Btu/hW
COP Heating
-
11.33 Btu/hW
Electrical Data
-
Voltage
-
150 – 265 V
-
-
Running current Cooling
-
10.4 A
-
-
Running current Heating
-
9.8 A
-
-
Power input Cooling
-
2297 W
-
-
Power input Heating
-
2162 W
-
Pipe Extension
-
Maximum Pipe Length
-
15 m
-
-
Maximum Height Difference
-
5 m
-
Operating (Ambient) Temperature
-
55°C
Net Dimension (IDU / ODU) H x W x D
-
220 x 1010 x 315 / 699 x 927 x 380 mm
Gross Dimension (IDU / ODU) H x W x D
-
297 x 1096 x 390 / 732 x 960 x 430 mm
Net / Gross Weight (Kg)
-
IDU / ODU
-
13/42 Kg (N) / 16/51 Kg (G)
-
Country of Origin
-
China
